F3L8MXTR12C2M2Q_H11 Infineon - IGBT Module
Also written as: F3L8MXTR12C2M2Q-H11
F3L8MXTR12C2M2Q_H11 Description
F3L8MXTR12C2M2Q_H11 is a 1200 V / 75 A 3-level IGBT module from Infineon Technologies. Typical applications: high-frequency switching application, DC/DC converter, DC charger for EV.
USComponent supplies F3L8MXTR12C2M2Q_H11 and other Infineon power modules. Request a quote for price and lead time - we reply within 24 hours.
Summary of Features
- Low inductive design
- Low switching losses
- High current density
- PressFIT contact technology
- Integrated NTC temperature sensor
Target Applications
Infineon F3L8MXTR12C2M2Q_H11 is used for High-frequency switching application, DC/DC converter, DC charger for EV.
Key Specifications
F3L8MXTR12C2M2Q_H11 is a 1200 V / 75 A 3-level IGBT module from Infineon Technologies (EasyPACK package). Source: Infineon datasheet and product table.
| Parameter | Value |
|---|---|
| Manufacturer | Infineon Technologies |
| Product type | IGBT module |
| Configuration | 3-level |
| Drain-source voltage (VDSS) | 1200 V |
| Nominal drain current (ID nom) | 75 A |
| Package | EasyPACK |
| Datasheet | Available on this page (PDF) |
Technical document (PDF) | Request a quote for F3L8MXTR12C2M2Q_H11 (reply within 24 hours)
Related Part Numbers
| F3L8MXTR12C2M2_H11 1200V, 75A | F3L8MR12W2M1HP_B11 1200V, 100A | F3L80R12W1H3_B11 1200V, 80A | F3L75R12W1H3_B27 1200V, 75A |
| F3L75R12W1H3_B11 1200V, 75A | F3L75R07W2E3_B11 650V, 75A | F3L6MR20W2M1H_B70 2000V, 100A | F3L600R10W4S7F_H11 950V, 600A |
| F3L600R10W4S7F_C22 950V, 600A | F3L600R10N3S7F 950V, 600A | F3L50R06W1E3_B11 600V, 50A | F3L500R12W3H7_H20 1200V, 500A |
| F3L500R12W3H7_H11 1200V, 500A | F3L500R12N3H7_B66 1200V, 510A | F3L500R12N3H7F_B66 1200V, 510A | F3L420R12W4H7_H11 1200V, 250A |
