MG200Q1JS9 Toshiba - IGBT Module

MG200Q1JS9 Description

Toshiba makes the MG200Q1JS9, an IGBT module. The module contains a single switch with its freewheeling diode (1-in-1). You'll typically find it in variable-frequency drives, servo amplifiers, UPS systems, welding machines and solar or wind inverters. If you are repairing older equipment, we can usually find this exact part, including date codes that are no longer in production.

Looking for a replacement MG200Q1JS9? USComponent can quote new and hard-to-find stock and ships worldwide. Request a quote for pricing and lead time, and double-check the datasheet to make sure it fits your application.

Summary of Features

Target Applications

Toshiba MG200Q1JS9 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

MG200Q1JS9 is a 1,200 V, 200 A IGBT / power transistor module, single configuration. Source: manufacturer datasheet.

Parameter	Value
Product type	IGBT / power transistor module
Configuration	Single
Collector-emitter voltage (VCES)	1,200 V
Collector current (IC)	200 A
Datasheet	Available on this page (PDF)
