MG25N2YS51 Toshiba - IGBT Module

MG25N2YS51 Description

Rated at 1000 V and 25 A, the Toshiba MG25N2YS51 is an IGBT module. The module contains two switches in a half-bridge (2-in-1) arrangement. It is a common choice for inverter stages in AC drives, servo systems, welders and uninterruptible power supplies.

We help engineers and repair technicians find parts like the MG25N2YS51, including obsolete ones. Send a quick RFQ for current pricing and delivery. Before ordering, please confirm ratings and pin-out with the official datasheet.

Summary of Features

Target Applications

Toshiba MG25N2YS51 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

MG25N2YS51 is a 1,000 V, 25 A IGBT / power transistor module, dual configuration. Source: manufacturer datasheet.

Parameter	Value
Product type	IGBT / power transistor module
Configuration	Dual
Collector-emitter voltage (VCES)	1,000 V
Collector current (IC)	25 A
Datasheet	Available on this page (PDF)
