MG100Q2ZS40 Toshiba - Power Transistor Module

Category: Darlington / Bipolar Transistor Modules

Specifications: 1200V, 100A

MG100Q2ZS40, Toshiba, Power Module

Representative image – actual product may differ

Availability and lead time are confirmed in our quote.

  • ✓ Quote within 24 hours
  • ✓ Original manufacturer parts, inspected before shipping
  • ✓ Credit cards and NET terms accepted

Or email sales@uscomponent.com or call 1-281-968-0718.

MG100Q2ZS40 Description

The Toshiba MG100Q2ZS40 is a Darlington transistor module, rated for 1200 V and 100 A. It was a workhorse in drives and power supplies before IGBTs took over, and it is still needed to repair that equipment.

USComponent (Young & New Century LLC) supplies power modules, thyristors, diodes and other industrial components, including legacy parts. Contact us for a quote on the MG100Q2ZS40, and please confirm ratings against the datasheet before ordering.

Target Applications

Toshiba MG100Q2ZS40 is used for motor drives and inverters, servo amplifiers, UPS systems, welding machines and other industrial power switching equipment.

Key Specifications

ManufacturerToshiba
CategoryPower Transistor Modules
Rated voltage1200 V
Rated current100 A

Related Part Numbers

MG100Q1ZS40
1200V, 100A		MG75Q2ZS50
1200V, 300A		MG100Q1ZS9
1200V, 100A		MG100Q1ZS50
1200V, 150A
MG200Q1ZS40
1200V, 200A		MG75Q1ZS50
1200V, 75A		MG50Q1ZS50
1200V, 50A		MG100Q6ES60
1200V, 100A
MG100Q2YS91
1200V, 100A		MG100Q2YS9
1200V, 100A		MG100Q2YS65H
1200V, 100A		MG100Q2YS51
1200V, 150A
MG100Q2YS50
1200V 150A		MG100Q2YS44
1200V, 100A		MG100Q2YS43
1200V, 100A		MG100Q2YS42
1200V, 100A
