MIG75Q202H Toshiba - IGBT Power Transistor Module

Category: Intelligent Power Modules (IPM)

Specifications: 1200V, 75A

MIG75Q202H IGBT Power Transistor Module from Toshiba

Representative image – actual product may differ

Availability and lead time are confirmed in our quote.

  • ✓ Quote within 24 hours
  • ✓ Original manufacturer parts, inspected before shipping
  • ✓ Credit cards and NET terms accepted

Or email sales@uscomponent.com or call 1-281-968-0718.

MIG75Q202H Description

MIG75Q202H is an intelligent power module, IGBT inverter + brake with control circuits from Toshiba, rated 1200V, 75A. Typical applications: High power switching applications and motor control applications.

USComponent supplies MIG75Q202H and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Summary of Features

  • Integrates inverter, brake power circuits & control circuits (IGBT drive units, protection units for over-current, realtime-current-control, under-voltage & over-temperature) in one package
  • The electrodes are isolated from case
  • High speed type IGBT

Target Applications

Toshiba MIG75Q202H is used for High power switching applications and motor control applications.

Key Specifications

MIG75Q202H is an intelligent power module, IGBT inverter + brake with control circuits from Toshiba, rated 1200V, 75A. Source: manufacturer datasheet.

ParameterValue
ManufacturerToshiba
Collector-emitter voltage VCES1200 V
Supply voltage VCC (P-N)900 V
Inverter collector current IC (Tc = 25 °C)75 A
Collector power dissipation (inverter)400 W
VCE(sat) max.3.5 V
toff max. / trr max.2.8 µs / 0.21 µs
Isolation voltage2500 V (AC 1 min)
Package / weightTOSHIBA 2-110A1A, 520 g
DatasheetAvailable on this page (PDF)

Technical document (PDF)  |  Request a quote for MIG75Q202H (reply within 24 hours)
