PM300DSA060 Mitsubishi Intelligent Power Module

PM300DSA060 Description

Flat-base Type Insulated Package Intelligent Power Module

Summary of Features

PM300DSA060 is a 600V 300A Intelligent Power Module.

Target Applications

Mitsubishi PM300DSA060 is used for Inverters, UPS, Motion/Servo Control and Power Supplies.

Key Specifications

Manufacturer	Mitsubishi Electric
Configuration	IPM, dual (2-in-1)
VCES	600 V
IC nom	300 A
Similar-rating parts	PM300DHA060 (same nominal voltage and current rating, for reference only. Package, pinout and characteristics may differ; please compare datasheets to determine suitability)
