PM100DSA-120 Mitsubishi - Intelligent Power Module

PM100DSA-120 Description

The Mitsubishi Electric PM100DSA-120 is an intelligent power module (IPM), rated for 100 A. It is mostly used in small and mid-size AC drives and servo amplifiers, where built-in gate drive and protection save board space.

USComponent has been supplying power semiconductors since 2001, including discontinued and hard-to-find part numbers. Send us an RFQ for the PM100DSA-120 and we will reply with price, condition and lead time. Please check the manufacturer's datasheet to confirm ratings, package and pin-out before you order.

Summary of Features

Target Applications

Mitsubishi PM100DSA-120 is used for Inverters, UPS, Motion/Sevo Control, Power Supplies.

Key Specifications

PM100DSA-120 is a 1,200 V, 100 A intelligent power module (IPM). Source: manufacturer datasheet.

Parameter	Value
Product type	Intelligent power module (IPM)
Collector-emitter voltage (VCES)	1,200 V
Collector current (IC)	100 A
Datasheet	Available on this page (PDF)

PM100DSA-120 Video

Technical document (PDF)  |  Request a quote for PM100DSA-120 (reply within 24 hours)
