DD241S16 Infineon - Diode Module

Category: Diode & Rectifier Modules

DD241S16 Infineon Diode Module

Representative image – actual product may differ

Availability and lead time are confirmed in our quote.

  • ✓ Quote within 24 hours
  • ✓ Original manufacturer parts, inspected before shipping
  • ✓ Credit cards and NET terms accepted

Or email sales@uscomponent.com or call 1-281-968-0718.

DD241S16 Description

Infineon Technologies DD241S16 is a diode module. Diode modules like this are common in rectifier front ends, DC power supplies, welders and plating equipment.

We help engineers and repair technicians find parts like the DD241S16, including obsolete ones. Send a quick RFQ for current pricing and delivery. Before ordering, please confirm ratings and pin-out with the official datasheet.

Target Applications

Infineon DD241S16 is used for AC/DC power conversion and control: controlled and uncontrolled rectifiers, DC motor drives, soft starters, battery chargers, welding equipment, heater and temperature control, and AC power controllers.

Key Specifications

DD241S16 is an eupec (Infineon) PowerBLOCK fast diode module. Source: eupec Power Semiconductors Shortform Catalog 2003 (catalog page available on this page as PDF).

ParameterValue
Manufacturereupec (Infineon Technologies)
Product typePowerBLOCK fast diode module
Repetitive peak reverse voltage (VRRM), series range1000 to 1400 V
Average forward current (IFAVM), 180° el sin240 A at Tc = 100 °C
RMS current (IFRMSM)410 A
Surge current (IFSM), 10 ms, Tvj max7500 A
I²t, 10 ms, Tvj max281.00 × 10³ A²s
Threshold voltage V(T0)1.10 V
Slope resistance rT0.5 mΩ
Peak reverse recovery current IRM135 A
Thermal resistance RthJC0.15 °C/W
Thermal resistance RthCK0.04 °C/W
Max. junction temperature Tvj max150 °C
Package (outline)DP50

Technical document (PDF)  |  Request a quote for DD241S16 (reply within 24 hours)

Related Part Numbers

DD230S16DD241S12DD121S16DD81S16
DD61S16
1600V, 61A		DD46S16DD230S12
1200V, 230A		DD121S12
1200V, 121A
DD241S16K
1600(V) / 241(A)		DD241S14K-K
1400V, 240A		DD241S18K
1800(V) / 241(A)		DD241S14K-A
1400V, 240A
DD241S14K
1400(V) / 241(A)		DD241S12K-K
1200V, 241A		DD241S12K-A
1200V, 241A		DD241S12K
1200V, 241A
