DD241S12 Infineon - Diode Module

Category: Diode & Rectifier Modules

DD241S12 Infineon Diode Module

Representative image – actual product may differ

Availability and lead time are confirmed in our quote.

  • ✓ Quote within 24 hours
  • ✓ Original manufacturer parts, inspected before shipping
  • ✓ Credit cards and NET terms accepted

Or email sales@uscomponent.com or call 1-281-968-0718.

DD241S12 Description

Infineon Technologies makes the DD241S12, a diode module. Typical applications include AC-to-DC rectification in drives and power supplies, freewheeling paths and battery charging.

USComponent has been supplying power semiconductors since 2001, including discontinued and hard-to-find part numbers. Send us an RFQ for the DD241S12 and we will reply with price, condition and lead time. Please check the manufacturer's datasheet to confirm ratings, package and pin-out before you order.

Target Applications

Infineon DD241S12 is used for AC/DC power conversion and control: controlled and uncontrolled rectifiers, DC motor drives, soft starters, battery chargers, welding equipment, heater and temperature control, and AC power controllers.

Key Specifications

DD241S12 is an eupec (Infineon) PowerBLOCK fast diode module. Source: eupec Power Semiconductors Shortform Catalog 2003 (catalog page available on this page as PDF).

ParameterValue
Manufacturereupec (Infineon Technologies)
Product typePowerBLOCK fast diode module
Repetitive peak reverse voltage (VRRM)1200 V (series 1000 to 1400 V)
Average forward current (IFAVM), 180° el sin240 A at Tc = 100 °C
RMS current (IFRMSM)410 A
Surge current (IFSM), 10 ms, Tvj max7500 A
I²t, 10 ms, Tvj max281.00 × 10³ A²s
Threshold voltage V(T0)1.10 V
Slope resistance rT0.5 mΩ
Peak reverse recovery current IRM135 A
Thermal resistance RthJC0.15 °C/W
Thermal resistance RthCK0.04 °C/W
Max. junction temperature Tvj max150 °C
Package (outline)DP50

Technical document (PDF)  |  Request a quote for DD241S12 (reply within 24 hours)

Related Part Numbers

DD230S12
1200V, 230A		DD241S16DD121S12
1200V, 121A		DD81S12
1200V, 81A
DD61S12
1200V, 61A		DD46S12DD230S16DD121S16
DD241S12K
1200V, 241A		DD241S08K
800V, 241A		DD241S12K-A
1200V, 241A		DD241S06K
6000(V) / 241(A)
DD241S12K-K
1200V, 241A		DD241S04K
4000(V) / 241(A)		DD241S14K
1400(V) / 241(A)		DD241S02K
2000(V) / 241(A)
