MG500Q1US41Toshiba - IGBT Power Transistor Module

MG500Q1US41 Description

The Toshiba MG500Q1US41 is an IGBT module rated at 1200 V and 500 A. Typical applications for this type of device include variable-frequency motor drives, servo drives, UPS systems, welding machines, induction heating and solar or wind inverters.

USComponent, a BBB A+ accredited business, helps engineers and maintenance teams source power semiconductors and industrial components, including older and hard-to-find part numbers. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the MG500Q1US41.

Target Applications

Toshiba MG500Q1US41 is used for High Power Switching Applications and Motor Control Applications.

Key Specifications

Manufacturer	Toshiba
Category	IGBT Power Transistor Module
Rated voltage	1200 V
Rated current	500 A

Download MG500Q1US41 Datasheet

Datasheet not available
