PM15RHB120Mitsubishi - Intelligent Power Module

PM15RHB120 Description

The Mitsubishi Electric PM15RHB120 is an intelligent power module (IPM) rated at 1200 V and 15 A. IGBT Power Transistor Modules POWER MODULE 3-PHASE BRAKE IGBT. Components of this type are commonly used in compact motor drives, servo amplifiers and inverter-based equipment, where the IPM combines power switches with built-in gate drive and protection circuitry.

USComponent supplies power semiconductors and industrial electronic components to engineers, OEMs and maintenance teams worldwide, including legacy and hard-to-find part numbers. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the PM15RHB120.

Target Applications

Mitsubishi PM15RHB120 is used for General Purpose Inverter, Uninterruptible Power Supply, Servo & Spindle Drive for CNC Machine Tools, Robotics (Servo Drive for Robots), Switching Power Supplies for Welding Machines.

Key Specifications

Manufacturer	Mitsubishi Electric
Category	Intelligent Power Module
Rated voltage	1200 V
Rated current	15 A

Download PM15RHB120 Datasheet

Datasheet not available
