PM15CNA060-12Mitsubishi - IPM

PM15CNA060-12 Description

Mitsubishi Electric PM15CNA060-12 is an intelligent power module (IPM) rated at 600 V and 15 A. Components of this type are commonly used in compact motor drives, servo amplifiers and inverter-based equipment, where the IPM combines power switches with built-in gate drive and protection circuitry.

USComponent supplies power semiconductors and industrial electronic components to engineers, OEMs and maintenance teams worldwide, including legacy and hard-to-find part numbers. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the PM15CNA060-12.

Summary of Features

Target Applications

Mitsubishi PM15CNA060-12 is used for General Purpose Inverter, Uninterruptible Power Supply, Servo & Spindle Drive for CNC Machine Tools, Robotics (Servo Drive for Robots), Switching Power Supplies for Welding Machines.

Key Specifications

PM15CNA060-12 is a 600 V, 15 A intelligent power module (IPM). Source: manufacturer datasheet.

Parameter	Value
Product type	Intelligent power module (IPM)
Collector-emitter voltage (VCES)	600 V
Collector current (IC)	15 A
Datasheet	Available on this page (PDF)

Download PM15CNA060-12 Datasheet

PM15CNA060-12 PDF Datasheet
