CM900HC-90H Mitsubishi - IGBT Module

CM900HC-90H Description

CM900HC-90H is a HVIGBT module (3rd version), 1 element in a pack, AlSiC baseplate from Mitsubishi Electric, rated 4500V, 900A. Typical applications: Traction drives, high reliability converters / inverters and DC choppers.

USComponent supplies CM900HC-90H and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Summary of Features

Target Applications

Mitsubishi CM900HC-90H is used for Traction drives, high reliability converters / inverters and DC choppers.

Key Specifications

CM900HC-90H is a HVIGBT module (3rd version), 1 element in a pack, AlSiC baseplate from Mitsubishi Electric, rated 4500V, 900A. Source: manufacturer datasheet.

Parameter	Value
Manufacturer	Mitsubishi Electric
Collector-emitter voltage VCES	4500 V
Collector current IC (DC, Tc = 100 °C)	900 A
ICM (pulse)	1800 A
VCE(sat) typ. (IC = 900 A, 25 °C)	3.45 V
Max. power dissipation (Tc = 25 °C)	11900 W
Isolation voltage	6000 V RMS, 1 min
Datasheet	Available on this page (PDF)

Note: Rated 900 A (DB value 950 A corrected).

Technical document (PDF)  |  Request a quote for CM900HC-90H (reply within 24 hours)
