DCG85X1200NA IXYS - Diode Module
DCG85X1200NA Description
DCG85X1200NA is a 1200 V / 41 A SiC Schottky diode module from IXYS (SOT-227B (minibloc) package). Typical applications: solar inverter, Uninterruptible power supply (UPS), Welding equipment, Switched-mode power supplies, Medical equipment, High speed rectifier.
USComponent supplies DCG85X1200NA and other IXYS power modules. Request a quote for price and lead time - we reply within 24 hours.
Summary of Features
- Ultra fast switching
- Zero reverse recovery
- Zero forward recovery
- Temperature independent switching behavior
- Positive temperature coefficient of forward voltage
- TVJM = 175°C
Target Applications
IXYS DCG85X1200NA is used for Solar inverter, Uninterruptible power supply (UPS), Welding equipment, Switched-mode power supplies, Medical equipment, High speed rectifier.
Key Specifications
DCG85X1200NA is a 1200 V / 41 A SiC Schottky diode module from IXYS (now part of Littelfuse) in a SOT-227B (minibloc) package. Source: IXYS (Littelfuse) datasheet and product data.
| Parameter | Value |
|---|---|
| Manufacturer | IXYS (Littelfuse) |
| Product type | SiC Schottky diode module |
| Configuration | Dual Diodes |
| Repetitive peak reverse voltage (VRRM) | 1200 V |
| Average forward current (IFAV) | 41 A |
| Package | SOT-227B (minibloc) |
| Isolation voltage | 2500 V~ |
| Weight | 30 g |
| Supply status | Obsolete |
| Datasheet | Available on this page (PDF) |
Status: IXYS / Littelfuse lists DCG85X1200NA as obsolete. USComponent can still source DCG85X1200NA and help you find a suitable alternative.
Technical document (PDF) | Request a quote for DCG85X1200NA (reply within 24 hours)
