FZ800R45KL3_B5 Infineon - IGBT Module
FZ800R45KL3_B5 Description
FZ800R45KL3_B5 is a 4500 V, 800 A Infineon IHV (highly insulated) IGBT module (single switch), used for traction converters, medium-voltage drives and power transmission.
USComponent supplies FZ800R45KL3_B5 and other Infineon power modules. Request a quote for price and lead time - we reply within 24 hours.
Summary of Features
- 4,500 V / 800 A single-switch high-voltage IGBT module
- Trench/Fieldstop IGBT3, high short-circuit capability
- Highly insulated module, AlSiC base plate
- High creepage and clearance distances, CTI > 600
Target Applications
Infineon FZ800R45KL3_B5 is used for Traction converters, medium-voltage drives and power transmission.
Key Specifications
FZ800R45KL3_B5 is a 4,500 V, 800 A Infineon IGBT module. Source: manufacturer datasheet.
| Parameter | Value |
|---|---|
| Product type | IGBT module |
| Configuration | Single switch (1-in-1) |
| Collector-emitter voltage (VCES) | 4,500 V |
| Collector current (IC nom) | 800 A |
| Technology | Trench/Fieldstop IGBT3 with Emitter Controlled 3 diode |
| Package | IHV (highly insulated), AlSiC base plate |
Technical document (PDF) | Request a quote for FZ800R45KL3_B5 (reply within 24 hours)
