FZ1800R12KF4_S1 Infineon - IGBT Module

FZ1800R12KF4_S1 Description

The FZ1800R12KF4_S1 from Infineon Technologies is an IGBT module. It is built with a single switch with its freewheeling diode (1-in-1). You'll typically find it in variable-frequency drives, servo amplifiers, UPS systems, welding machines and solar or wind inverters.

USComponent is a BBB A+ accredited distributor that specializes in power modules and industrial components, new and legacy. Ask us for a quote on the FZ1800R12KF4_S1; we ship worldwide. Please verify the ratings and package against the manufacturer's datasheet first.

Summary of Features

Target Applications

Infineon FZ1800R12KF4_S1 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

FZ1800R12KF4_S1 is a 1,200 V, 1800 A IGBT module, single switch configuration. Source: manufacturer datasheet.

Parameter	Value
Product type	IGBT module
Configuration	Single switch
Collector-emitter voltage (VCES)	1,200 V
Collector current (IC)	1800 A
Datasheet	Available on this page (PDF)

Status: discontinued by Infineon (Product Discontinuation PD_099_15, last order date 2017-03-31). Infineon recommended replacement: FZ1800R12HE4_B9. Infineon notes that a replacement is not always a one-to-one drop-in: check the datasheet limits and gate drive conditions. USComponent can still source the original FZ1800R12KF4_S1 as well as the replacement.

Technical document (PDF)  |  Request a quote for FZ1800R12KF4_S1 (reply within 24 hours)
