RM400HA-20SMitsubishi - Diode Module

RM400HA-20S Description

Mitsubishi Electric RM400HA-20S is a diode module rated at 1000 V and 400 A. Typical applications for this type of device include input rectifiers for drives and power supplies, battery chargers, welding equipment and freewheeling circuits.

USComponent specializes in sourcing power modules and industrial electronic components, including legacy and hard-to-find parts for repair and maintenance. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the RM400HA-20S.

Summary of Features

Target Applications

Mitsubishi RM400HA-20S is used for AC/DC power conversion and control: controlled and uncontrolled rectifiers, DC motor drives, soft starters, battery chargers, welding equipment, heater and temperature control, and AC power controllers.

Key Specifications

RM400HA-20S is a 1,000 V, 400 A rectifier diode module. Source: manufacturer datasheet.

Parameter	Value
Product type	Rectifier diode module
Repetitive peak reverse voltage (VRRM)	1,000 V
Rated forward / output current	400 A
Datasheet	Available on this page (PDF)

Download RM400HA-20S Datasheet

RM400HA-20S PDF Datasheet
