QM100E2Y-HMitsubishi - Power Transistor Module

QM100E2Y-H Description

The Mitsubishi Electric QM100E2Y-H is a Darlington transistor module rated at 600 V and 100 A, available from USComponent. Components of this type are commonly used in motor drives, UPS systems and power supplies; transistor modules of this type are largely superseded by IGBTs in new designs but remain essential for maintaining installed equipment.

USComponent supplies power semiconductors and industrial electronic components to engineers, OEMs and maintenance teams worldwide, including legacy and hard-to-find part numbers. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the QM100E2Y-H.

Target Applications

Mitsubishi QM100E2Y-H is used for UPS and CVCF.

Key Specifications

Manufacturer	Mitsubishi Electric
Category	Power Transistor Modules
Rated voltage	600 V
Rated current	100 A

Download QM100E2Y-H Datasheet

QM100E2Y-H PDF Datasheet
