PS11037 Mitsubishi - Power Transistor Module

Category: Intelligent Power Modules (IPM)

Specifications: 600V, 50A

PS11037 Mitsubishi Power Transistor Module

Representative image – actual product may differ

Availability and lead time are confirmed in our quote.

  • ✓ Quote within 24 hours
  • ✓ Original manufacturer parts, inspected before shipping
  • ✓ Credit cards and NET terms accepted

Or email sales@uscomponent.com or call 1-281-968-0718.

PS11037 Description

PS11037 is an application specific IPM (ASIPM) with 3 phase converter bridge from Powerex / Mitsubishi, rated 600V, 50A. Typical applications: Small motor control, general purpose inverters and pump and HVAC motor control.

USComponent supplies PS11037 and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Summary of Features

  • Compact packages
  • 3 phase converter bridge built-in
  • Integrated HVICs
  • Direct connection to DSP/CPU

Target Applications

Mitsubishi PS11037 is used for Small motor control, general purpose inverters and pump and HVAC motor control.

Key Specifications

PS11037 is an application specific IPM (ASIPM) with 3 phase converter bridge from Powerex / Mitsubishi, rated 600V, 50A. Source: manufacturer datasheet.

ParameterValue
ManufacturerPowerex / Mitsubishi
Each IGBT collector-emitter voltage600 V
Each IGBT collector current ±IC (Tc = 25 °C)50 A (peak 100 A)
Isolation voltage2500 V
Switching frequencyup to 20 kHz
DatasheetAvailable on this page (PDF)

Note: Rated 600 V, 50 A.

Technical document (PDF)  |  Request a quote for PS11037 (reply within 24 hours)

Related Part Numbers

PS11036
15V, 60A		PS11035
600(V) / 20(A)		PS11034
15(V) / 30(A)		PS11033
15(V) / 16(A)
PS11032
15(V) / 8(A)		PS11017PS11016
15(V) / 60(A)		PS11015
15(V) / 40(A)
PS11037-Y2
600V, 100A		PS11036-1
600(V) / 30(A)		PS11035-1
600V, 20A		PS11034-Y1
600(V) / 15(A)
PS11032-A01
600(V) / 4(A)		PS11044SA529185-03PS11046-SA529186-01PS12012
5(V) / 10(A)
