PS11035 Mitsubishi - Power Transistor Module

PS11035 Description

The PS11035 from Mitsubishi Electric is an intelligent power module (IPM) with a 600 V / 20 A rating. Because the gate drivers and protection circuits are built in, it is popular in compact motor drives, servo amplifiers and appliance inverters.

USComponent has been supplying power semiconductors since 2001, including discontinued and hard-to-find part numbers. Send us an RFQ for the PS11035 and we will reply with price, condition and lead time. Please check the manufacturer's datasheet to confirm ratings, package and pin-out before you order.

Summary of Features

Target Applications

Mitsubishi PS11035 is used for Small Motor Control, Small Servo Motors, General Purpose Inverters, Pump and HVAC Motor Control.

Key Specifications

Manufacturer	Mitsubishi Electric
Category	Power Transistor Modules
Rated voltage	600 V
Rated current	20 A

Technical document (PDF)  |  Request a quote for PS11035 (reply within 24 hours)
