PM30CNA060 Mitsubishi Intelligent Power Module

PM30CNA060 Description

IGBT POWER TRANSISTOR MODULE

Target Applications

Mitsubishi PM30CNA060 is used for General Purpose Inverter, Uninterruptible Power Supply, Servo & Spindle Drive for CNC Machine Tools, Robotics (Servo Drive for Robots), Switching Power Supplies for Welding Machines.

Key Specifications

Manufacturer	Mitsubishi Electric
Configuration	IPM, six-pack (6-in-1)
VCES	600 V
IC nom	30 A
Similar-rating parts	6MBP30RH060, PM30CSJ060, PM30CMA060, PM30CNJ060 (same nominal voltage and current rating, for reference only. Package, pinout and characteristics may differ; please compare datasheets to determine suitability)

PM30CNA060 Video

Download PM30CNA060 Datasheet

Datasheet not available
