PM15CHA-060Mitsubishi - Intelligent Power Module

PM15CHA-060 Description

The Mitsubishi Electric PM15CHA-060 is an intelligent power module (IPM) rated at 600 V and 20 A. This type of device is widely used in compact motor drives, servo amplifiers and inverter-based equipment, where the IPM combines power switches with built-in gate drive and protection circuitry.

USComponent supplies power semiconductors and industrial electronic components to engineers, OEMs and maintenance teams worldwide, including legacy and hard-to-find part numbers. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the PM15CHA-060.

Target Applications

Mitsubishi PM15CHA-060 is used for compact inverter stages in AC motor drives, servo amplifiers, air conditioner and appliance inverters, elevators and general purpose inverters.

Key Specifications

Manufacturer	Mitsubishi Electric
Category	Intelligent Power Module
Rated voltage	600 V
Rated current	20 A

Download PM15CHA-060 Datasheet

Datasheet not available
