IXFN80N50 IXYS - MOSFET Module

IXFN80N50 Description

IXFN80N50 is a HiPerFET power MOSFET, single die, miniBLOC SOT-227 B from IXYS, rated 500V, 80A. Typical applications: DC-DC converters, battery chargers, switched-mode and resonant-mode power supplies, DC choppers and temperature and lighting controls.

USComponent supplies IXFN80N50 and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Summary of Features

Target Applications

IXYS IXFN80N50 is used for DC-DC converters, battery chargers, switched-mode and resonant-mode power supplies, DC choppers and temperature and lighting controls.

Key Specifications

IXFN80N50 is a HiPerFET power MOSFET, single die, miniBLOC SOT-227 B from IXYS, rated 500V, 80A. Source: manufacturer datasheet.

Parameter	Value
Manufacturer	IXYS
Drain-source voltage VDSS	500 V
Drain current ID25 (TC = 25 °C)	80 A
Pulsed drain current IDM	320 A
On-resistance RDS(on)	50 mΩ
Power dissipation PD	700 W
Isolation voltage	2500 V~ (1 min)
Package	miniBLOC, SOT-227 B
Datasheet	Available on this page (PDF)

Note: data taken from the IXYS datasheet of IXFN 80N50 / IXFN 75N50, which covers IXFN80N50.

Technical document (PDF)  |  Request a quote for IXFN80N50 (reply within 24 hours)
