FZ3600R12KE3 Infineon - IGBT Module

FZ3600R12KE3 Description

Infineon Technologies makes the FZ3600R12KE3, an IGBT module. Inside, it has a single switch with its freewheeling diode (1-in-1). Modules like this do the heavy switching in motor drives, UPS systems, induction heaters and renewable-energy inverters. Many of these parts are still in service in machines built years ago, and a direct replacement is often the fastest way to get one running again.

USComponent is a BBB A+ accredited distributor that specializes in power modules and industrial components, new and legacy. Ask us for a quote on the FZ3600R12KE3; we ship worldwide. Please verify the ratings and package against the manufacturer's datasheet first.

Target Applications

Infineon FZ3600R12KE3 is used for motor drives and inverters, servo amplifiers, UPS systems, welding machines and other industrial power switching equipment.

Key Specifications

Manufacturer	Infineon Technologies (eupec)
Configuration	Single switch - IGBT with free-wheeling diode
Technology	IGBT3
VCES	1200 V
IC	3600 A (TC = 70 °C)
ICRM	7200 A (tp = 1 ms, TC = 80 °C)
Isolation test voltage	2.5 kV RMS, 50 Hz, 1 min

Status: discontinued by Infineon (Product Discontinuation PD_099_15, last order date 2017-03-31). Infineon recommended replacement: FZ3600R12HP4. Infineon notes that a replacement is not always a one-to-one drop-in: check the datasheet limits and gate drive conditions. USComponent can still source the original FZ3600R12KE3 as well as the replacement.
