MBM800GS33G2 Hitachi - IGBT Module

MBM800GS33G2 Description

MBM800GS33G2 is a 3,300 V / 800 A dual igbt module in the MBN / MBM / MBL family from Hitachi Power Semiconductor Device / MinebeaMitsumi. Manufacturer lists this model as a working sample; production availability is not established. Verify electrical ratings, package, terminals, isolation and exact ordering suffix against the manufacturer datasheet before ordering.

USComponent sources industrial power semiconductor modules including hard-to-find parts. Request a quote for MBM800GS33G2 price and availability.

Summary of Features

Target Applications

Hitachi MBM800GS33G2 finds applications in various industries and systems where high power switching is required.

Key Specifications

MBM800GS33G2 is listed in the official Hitachi Power Semiconductor Device / MinebeaMitsumi power module catalog.

Parameter	Value
Manufacturer	Hitachi Power Semiconductor Device / MinebeaMitsumi
Part number	MBM800GS33G2
Series	MBN / MBM / MBL
Device type	Dual IGBT module
Rated VCES	3,300 V
Catalog current rating	800 A
Manufacturer catalog status	Working sample
Official source	Manufacturer product lineup

Specifications are from the manufacturer lineup, not a verified complete product-specific datasheet. Confirm pinout, mechanical fit, gate-drive requirements and current ordering status.
