2MBI150NB-060Fuji Electric - IGBT power module

2MBI150NB-060 Description

2MBI150NB-060 is a high-power insulated-gate bipolar transistor (IGBT) module designed for use in industrial and commercial applications. It is manufactured using advanced IGBT technology and is capable of handling high voltages and currents with minimal switching losses. This module features a dual-chip IGBT design, which helps to improve efficiency and reduce switching losses. It is capable of handling up to 150 amps of current and can operate at voltages up to 600 volts. The 2MBI150NB-060 also includes a built-in temperature sensor that allows for precise thermal management, ensuring optimal performance and reliability. In addition to its high-performance IGBTs, this module includes a number of protective features, including short-circuit protection, overcurrent protection, and overvoltage protection. These features help to prevent damage to the module and other components in the system, and ensure safe and reliable operation. The 2MBI150NB-060 is designed for easy integration into existing motor control systems. It features standard connections for power input and output, as well as a number of control inputs and outputs for interfacing with a variety of control systems.

Target Applications

Fuji Electric 2MBI150NB-060 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

Manufacturer	Fuji Electric
Category	IGBT power module
Rated voltage	600 V
Rated current	150 A

Download 2MBI150NB-060 Datasheet

Datasheet not available
