2DI75Z-120(A) Fuji Electric - Darlington Module

Also written as: 2DI75Z-120A

Category: Darlington / Bipolar Transistor Modules

Specifications: 1000V, 75A

2DI75Z-120(A), Fuji, Fuji Electric power module

Representative image – actual product may differ

We beat competitor's price with faster delivery.

For 6 pieces or more, submit your inquiry here, email to sales@uscomponent.com or call 1-281-968-0718

2DI75Z-120(A) Description

Fuji Electric makes the 2DI75Z-120(A), a 1000 V, 75 A Darlington transistor module. It was a workhorse in drives and power supplies before IGBTs took over, and it is still needed to repair that equipment.

USComponent (Young & New Century LLC) supplies power modules, thyristors, diodes and other industrial components, including legacy parts. Contact us for a quote on the 2DI75Z-120(A), and please confirm ratings against the datasheet before ordering.

Target Applications

Fuji Electric 2DI75Z-120(A) is used for high-power traction inverters and choppers, medium-voltage motor drives, static VAR compensators and other high-power converters.

Key Specifications

ManufacturerFuji Electric
CategoryDarlington Module
Rated voltage1000 V
Rated current75 A

Technical document (PDF)  |  Request a quote for 2DI75Z-120(A) (reply within 24 hours)

Related Part Numbers

2DI75Z-140(A)
1400V, 75A		2DI75Z-100(A)
1000V, 100A		2DI150Z-120(A)
1200V, 150A		2DI30Z-120(A)
1200V, 30A
2DI100Z-140(A)
1400V / 100A		2DI50Z-100(A)
1000V, 50A		2DI50Z-140(A)
1400V, 50A		2DI30Z-100(A)
1000V, 30A
2DI75Z-1002DI75Z-100E2DI75Z-1202DI75Z-120-03
2DI75Z-1402DI75ZA-1002DI75A-0502DI75A-120
