2DI75S-050A Fuji Electric - Bipolar Transistor Module

2DI75S-050A Description

Fuji Electric makes the 2DI75S-050A, a 600 V power transistor (bipolar darlington) module. It is built with two switches in a half-bridge (2-in-1) arrangement. It was a workhorse in drives and power supplies before IGBTs took over, and it is still needed to repair that equipment.

USComponent is a BBB A+ accredited distributor that specializes in power modules and industrial components, new and legacy. Ask us for a quote on the 2DI75S-050A; we ship worldwide. Please verify the ratings and package against the manufacturer's datasheet first.

Summary of Features

Target Applications

Fuji Electric 2DI75S-050A is used for DC Chopper.

Key Specifications

2DI75S-050A is a 500 V, 75 A power transistor (bipolar Darlington) module, dual configuration. Source: manufacturer datasheet.

Parameter	Value
Product type	Power transistor (bipolar Darlington) module
Configuration	Dual
Collector-emitter voltage (VCES)	500 V
Collector current (IC)	75 A
Datasheet	Available on this page (PDF)

Technical document (PDF)  |  Request a quote for 2DI75S-050A (reply within 24 hours)
