PM100RSA060 Mitsubishi - Intelligent Power Module

PM100RSA060 Description

The PM100RSA060 from Mitsubishi Electric is an intelligent power module (IPM). An IPM like this simplifies inverter design: drive, short-circuit and over-temperature protection are already inside the package. Many of these parts are still in service in machines built years ago, and a direct replacement is often the fastest way to get one running again.

USComponent (Young & New Century LLC) supplies power modules, thyristors, diodes and other industrial components, including legacy parts. Contact us for a quote on the PM100RSA060, and please confirm ratings against the datasheet before ordering.

Summary of Features

Target Applications

Mitsubishi PM100RSA060 is used for compact inverter stages in AC motor drives, servo amplifiers, air conditioner and appliance inverters, elevators and general purpose inverters.

Key Specifications

PM100RSA060 is a 600 V, 100 A intelligent power module (IPM). Source: manufacturer datasheet.

Parameter	Value
Product type	Intelligent power module (IPM)
Collector-emitter voltage (VCES)	600 V
Collector current (IC)	100 A
Datasheet	Available on this page (PDF)

Technical document (PDF)  |  Request a quote for PM100RSA060 (reply within 24 hours)
