PM100CL1A060Mitsubishi - Intelligent Power Module

PM100CL1A060 Description

PM100CL1A060 is a power module designed for high-power switching applications. It is manufactured by Mitsubishi Electric Corporation and consists of two insulated-gate bipolar transistors (IGBTs) and two free-wheeling diodes in a single module. This power module has a maximum collector current of 100A and a maximum collector-emitter voltage of 600V. It also features low saturation voltage and high-speed switching performance, making it suitable for use in various applications such as motor drives, inverters, and power supplies. The PM100CL1A060 is designed to be a reliable and efficient solution for high-power switching applications. Its compact and easy-to-use package simplifies circuit design and assembly. Additionally, the power module features an optimized thermal design that ensures effective heat dissipation, as well as advanced protection features such as short-circuit protection and over-temperature protection.

Target Applications

Mitsubishi PM100CL1A060 is used for general purpose inverter, servo drives and other motor controls.

Key Specifications

Manufacturer	Mitsubishi Electric
Category	Intelligent Power Module
Rated voltage	600 V
Rated current	100 A

Download PM100CL1A060 Datasheet

Datasheet not available
