CM50DY-24HMitsubishi - IGBT Module

CM50DY-24H Description

CM50DY-24H is an Insulated Gate Bipolar Transistor (IGBT) module designed for high-power switching applications. It is produced by Mitsubishi Electric Corporation and consists of two IGBTs in a half-bridge configuration. The IGBT module has a current rating of 50A and a voltage rating of 1200V. It also includes a built-in freewheeling diode for each IGBT, which allows for efficient switching and reduced power losses. The CM50DY-24H IGBT module is designed with low-on resistance and high-speed switching characteristics, making it suitable for use in various power electronics applications, such as motor drives, renewable energy systems, and industrial automation. It is also designed with a compact and robust package, which enables easy installation and provides high reliability in harsh operating environments. In addition, the CM50DY-24H IGBT module is equipped with a temperature sensor for over-temperature protection and has a low thermal resistance, which helps to improve its heat dissipation performance.

Target Applications

Mitsubishi CM50DY-24H is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

Manufacturer	Mitsubishi Electric
Category	IGBT Modules
Rated voltage	600 V
Rated current	50 A

Download CM50DY-24H Datasheet

CM50DY-24H PDF Datasheet
