TZ425N14KOF Infineon - SCR
Discontinued: Infineon recommended replacement: TZ425N16KOF. We supply both the original TZ425N14KOF and the replacement - check the datasheets before switching.
TZ425N14KOF Description
The TZ425N14KOF is a thyristor module made by Infineon Technologies (formerly Eupec). Typical applications include soft starters, AC power controllers, controlled rectifiers, DC motor drives and heating control. If you are repairing older equipment, we can usually find this exact part, including date codes that are no longer in production.
USComponent (Young & New Century LLC) supplies power modules, thyristors, diodes and other industrial components, including legacy parts. Contact us for a quote on the TZ425N14KOF, and please confirm ratings against the datasheet before ordering.
Target Applications
Infineon TZ425N14KOF is used for AC/DC power conversion and control: controlled and uncontrolled rectifiers, DC motor drives, soft starters, battery chargers, welding equipment, heater and temperature control, and AC power controllers.
Key Specifications
TZ425N14KOF is an eupec (Infineon) PowerBLOCK single thyristor module. Source: eupec Power Semiconductors Shortform Catalog 2003 (catalog page available on this page as PDF).
| Parameter | Value |
|---|---|
| Manufacturer | eupec (Infineon Technologies) |
| Product type | PowerBLOCK single thyristor module |
| Repetitive peak off-state / reverse voltage (VDRM / VRRM) | 1400 V (series 1000 to 1800 V) |
| Average on-state current (ITAVM), 180° el sin | 425 A at Tc = 85 °C |
| RMS current (ITRMSM) | 800 A |
| Surge current (ITSM), 10 ms, Tvj max | 12500 A |
| I²t, 10 ms, Tvj max | 781 × 10³ A²s |
| Threshold voltage V(T0) | 0.90 V |
| Slope resistance rT | 0.30 mΩ |
| Critical rate of rise of on-state current (di/dt)cr | 120 A/µs |
| Turn-off time tq, typ. | 250 µs |
| Critical rate of rise of off-state voltage (dv/dt)cr | 1000 V/µs |
| Thermal resistance RthJC | 0.078 °C/W |
| Thermal resistance RthCK | 0.02 °C/W |
| Max. junction temperature Tvj max | 125 °C |
| Package (outline) | TP50.1 |
Technical document (PDF) | Request a quote for TZ425N14KOF (reply within 24 hours)
Related Part Numbers
| TZ430N14KOF 1400(V) / 430(A) | TZ400N14KOF 1400V, 400A | TZ375N14KOF 1400(V) / 375(A) | TZ425N16KOF 1600V, 800A |
| TZ425N12KOF 1200V, 425A | TZ500N14KOF 1400(V) / 500(A) | TZ425N18KOF 1800V, 425A | TZ600N14KOF 1400V, 600A |
| TZ425N16 1600V, 425A | TZ425N12 1200V, 425A | TZ425N18 1800V, 425A | TZ425N08KOF 425A / 800V |
| TZ425N08 800V, 425A | TZ425N20 2000V, 425A | TZ400N26KOF 2600V, 400A | TZ430N08 800V, 430A |
