DD61S14K Infineon - Power Transistor Module

DD61S14K Description

The DD61S14K from Infineon Technologies (formerly Eupec) is a diode module with a 1400 V / 76 A rating. Typical applications include AC-to-DC rectification in drives and power supplies, freewheeling paths and battery charging.

USComponent (Young & New Century LLC) supplies power modules, thyristors, diodes and other industrial components, including legacy parts. Contact us for a quote on the DD61S14K, and please confirm ratings against the datasheet before ordering.

Summary of Features

Target Applications

Infineon DD61S14K is used for motor drives and inverters, servo amplifiers, UPS systems, welding machines and other industrial power switching equipment.

Key Specifications

DD61S14K is an eupec (Infineon) PowerBLOCK fast diode module. Source: eupec Power Semiconductors Shortform Catalog 2003 (catalog page available on this page as PDF).

Parameter	Value
Manufacturer	eupec (Infineon Technologies)
Product type	PowerBLOCK fast diode module
Repetitive peak reverse voltage (VRRM)	1400 V (series 1000 to 1400 V)
Average forward current (IFAVM), 180° el sin	61 A at Tc = 100 °C
RMS current (IFRMSM)	120 A
Surge current (IFSM), 10 ms, Tvj max	1600 A
I²t, 10 ms, Tvj max	12.80 × 10³ A²s
Threshold voltage V(T0)	1.00 V
Slope resistance rT	2.2 mΩ
Peak reverse recovery current IRM	82 A
Thermal resistance RthJC	0.62 °C/W
Thermal resistance RthCK	0.16 °C/W
Max. junction temperature Tvj max	150 °C
Package (outline)	DP20

Technical document (PDF)  |  Request a quote for DD61S14K (reply within 24 hours)
