DD61S12K Infineon - Diode Module
Discontinued: Infineon recommended replacement: DD61S14K. We supply both the original DD61S12K and the replacement - check the datasheets before switching.
DD61S12K Description
Infineon Technologies makes the DD61S12K, a diode module. Diode modules like this are common in rectifier front ends, DC power supplies, welders and plating equipment.
USComponent is a BBB A+ accredited distributor that specializes in power modules and industrial components, new and legacy. Ask us for a quote on the DD61S12K; we ship worldwide. Please verify the ratings and package against the manufacturer's datasheet first.
Target Applications
Infineon DD61S12K is used for AC/DC power conversion and control: controlled and uncontrolled rectifiers, DC motor drives, soft starters, battery chargers, welding equipment, heater and temperature control, and AC power controllers.
Key Specifications
DD61S12K is an eupec (Infineon) PowerBLOCK fast diode module. Source: eupec Power Semiconductors Shortform Catalog 2003 (catalog page available on this page as PDF).
| Parameter | Value |
|---|---|
| Manufacturer | eupec (Infineon Technologies) |
| Product type | PowerBLOCK fast diode module |
| Repetitive peak reverse voltage (VRRM) | 1200 V (series 1000 to 1400 V) |
| Average forward current (IFAVM), 180° el sin | 61 A at Tc = 100 °C |
| RMS current (IFRMSM) | 120 A |
| Surge current (IFSM), 10 ms, Tvj max | 1600 A |
| I²t, 10 ms, Tvj max | 12.80 × 10³ A²s |
| Threshold voltage V(T0) | 1.00 V |
| Slope resistance rT | 2.2 mΩ |
| Peak reverse recovery current IRM | 82 A |
| Thermal resistance RthJC | 0.62 °C/W |
| Thermal resistance RthCK | 0.16 °C/W |
| Max. junction temperature Tvj max | 150 °C |
| Package (outline) | DP20 |
Technical document (PDF) | Request a quote for DD61S12K (reply within 24 hours)
Related Part Numbers
| DD53S12K 1200(V) / 64(A) | DD61S14K 1400V, 61A | DD46S12K 1200V, 45A | DD81S12K 1200V |
| DD121S12K | DD21S12K 1200(V) / 21(A) | DD230S12K 1200(V) / 230(A) | DD241S12K 1200V, 241A |
| DD61S12 1200V, 61A | DD61S14K-K 1400V | DD61S16 1600V, 61A | DD61N16K 1600(V) / 61(A) |
| DD61N1200K 1200(V) / 61(A) | DD61N06L 600V, 61A | DD65N1200K 1200V, 65A | DD68S800K-NA 800(V) / 68(A) |
