BSM400GA120DN2S_E3256 Infineon - IGBT Module

BSM400GA120DN2S_E3256 Description

Infineon Technologies makes the BSM400GA120DN2S_E3256, an IGBT module. You'll typically find it in variable-frequency drives, servo amplifiers, UPS systems, welding machines and solar or wind inverters.

Looking for a replacement BSM400GA120DN2S_E3256? USComponent can quote new and hard-to-find stock and ships worldwide. Request a quote for pricing and lead time, and double-check the datasheet to make sure it fits your application.

Summary of Features

Target Applications

Infineon BSM400GA120DN2S_E3256 is used for motor drives and inverters, servo amplifiers, UPS systems, welding machines and other industrial power switching equipment.

Key Specifications

BSM400GA120DN2SE3256 is a 1,200 V, 400 A IGBT module, single configuration. Source: manufacturer datasheet.

Parameter	Value
Product type	IGBT module
Configuration	Single
Collector-emitter voltage (VCES)	1,200 V
Collector current (IC)	400 A
Datasheet	Available on this page (PDF)

Status: discontinued by Infineon (Product Discontinuation PD_079_23, last order date 2023-09-30). Infineon recommended replacement: FZ400R12KE4. Infineon notes that a replacement is not always a one-to-one drop-in: check the datasheet limits and gate drive conditions. USComponent can still source the original BSM400GA120DN2S_E3256 as well as the replacement.

Technical document (PDF)  |  Request a quote for BSM400GA120DN2S_E3256 (reply within 24 hours)
