BSM300GA120DN2-SE3256 Infineon - IGBT Module

BSM300GA120DN2-SE3256 Description

The BSM300GA120DN2-SE3256 is an IGBT module made by Infineon Technologies. Modules like this do the heavy switching in motor drives, UPS systems, induction heaters and renewable-energy inverters.

Looking for a replacement BSM300GA120DN2-SE3256? USComponent can quote new and hard-to-find stock and ships worldwide. Request a quote for pricing and lead time, and double-check the datasheet to make sure it fits your application.

Summary of Features

Target Applications

Infineon BSM300GA120DN2-SE3256 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

BSM300GA120DN2SE3256 is a 1,200 V, 300 A IGBT module, single configuration. Source: manufacturer datasheet.

Parameter	Value
Product type	IGBT module
Configuration	Single
Collector-emitter voltage (VCES)	1,200 V
Collector current (IC)	300 A
Datasheet	Available on this page (PDF)

Status: discontinued by Infineon (Product Discontinuation PD_079_23, last order date 2023-09-30). Infineon recommended replacement: FZ400R12KE4. Infineon notes that a replacement is not always a one-to-one drop-in: check the datasheet limits and gate drive conditions. USComponent can still source the original BSM300GA120DN2S_E3256 as well as the replacement.

Technical document (PDF)  |  Request a quote for BSM300GA120DN2-SE3256 (reply within 24 hours)
