BSM400GA120DN2FS_E3256 Infineon - IGBT Module

BSM400GA120DN2FS_E3256 Description

The BSM400GA120DN2FS_E3256 from Infineon Technologies is an IGBT module. The module contains a single switch with its freewheeling diode (1-in-1). It is a common choice for inverter stages in AC drives, servo systems, welders and uninterruptible power supplies.

USComponent has sourced power semiconductors for maintenance teams and OEMs since 2001. For price and availability of the BSM400GA120DN2FS_E3256, send us a request for quote. Please confirm the specifications against the manufacturer's datasheet before purchase.

Summary of Features

Target Applications

Infineon BSM400GA120DN2FS_E3256 is used for motor drives and inverters, servo amplifiers, UPS systems, welding machines and other industrial power switching equipment.

Key Specifications

BSM400GA120DN2FS_E3256 is a 1,200 V, 400 A IGBT module, single configuration. Source: manufacturer datasheet.

Parameter	Value
Product type	IGBT module
Configuration	Single
Collector-emitter voltage (VCES)	1,200 V
Collector current (IC)	400 A
Datasheet	Available on this page (PDF)

Status: discontinued by Infineon (Product Discontinuation PD_079_23, last order date 2023-09-30). Infineon recommended replacement: FZ400R12KE4. Infineon notes that a replacement is not always a one-to-one drop-in: check the datasheet limits and gate drive conditions. USComponent can still source the original BSM400GA120DN2FS_E3256 as well as the replacement.

Technical document (PDF)  |  Request a quote for BSM400GA120DN2FS_E3256 (reply within 24 hours)
