2MBI150U4H-120 Fuji Electric - IGBT power module

2MBI150U4H-120 Description

2MBI150U4H-120 is an IGBT module (U series), 2 in one package from Fuji Electric, rated 1200V, 150A. Typical applications: Inverter for motor drive, AC and DC servo drive amplifier, uninterruptible power supply and industrial machines, such as welding machines.

USComponent supplies 2MBI150U4H-120 and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Summary of Features

Target Applications

Fuji Electric 2MBI150U4H-120 is used for Inverter for motor drive, AC and DC servo drive amplifier, uninterruptible power supply and industrial machines, such as welding machines.

Key Specifications

2MBI150U4H-120 is an IGBT module (U series), 2 in one package from Fuji Electric, rated 1200V, 150A. Source: manufacturer datasheet.

Parameter	Value
Manufacturer	Fuji Electric
Collector-emitter voltage VCES	1200 V
Collector current IC (Tc = 80 °C)	150 A
IC (Tc = 25 °C)	200 A
IC pulse (1 ms, Tc = 80 °C)	300 A
VCE(sat) typ., chip (IC = 150 A, Tj = 25 °C)	1.90 V
Collector power dissipation	780 W
Junction temperature Tj	+150 °C
Isolation voltage	2500 VAC, 1 min
Configuration	2 in one (half bridge)
Datasheet	Available on this page (PDF)
