MG400G1UL1 Toshiba - Bipolar Transistor Module

MG400G1UL1 Description

MG400G1UL1 is a 600 V, 400 A IGBT module made by Toshiba. It is a common choice for inverter stages in AC drives, servo systems, welders and uninterruptible power supplies. Many of these parts are still in service in machines built years ago, and a direct replacement is often the fastest way to get one running again.

We help engineers and repair technicians find parts like the MG400G1UL1, including obsolete ones. Send a quick RFQ for current pricing and delivery. Before ordering, please confirm ratings and pin-out with the official datasheet.

Summary of Features

Target Applications

Toshiba MG400G1UL1 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

MG400G1UL1 is a 400 A IGBT / power transistor module. Source: manufacturer datasheet.

Parameter	Value
Product type	IGBT / power transistor module
Collector current (IC)	400 A
Datasheet	Available on this page (PDF)

MG400G1UL1 Video

Technical document (PDF)  |  Request a quote for MG400G1UL1 (reply within 24 hours)
