MG150H2DL1 Description

Toshiba makes the MG150H2DL1, a 550 V, 150 A IGBT module. You'll typically find it in variable-frequency drives, servo amplifiers, UPS systems, welding machines and solar or wind inverters.

Looking for a replacement MG150H2DL1? USComponent can quote new and hard-to-find stock and ships worldwide. Request a quote for pricing and lead time, and double-check the datasheet to make sure it fits your application.

Summary of Features

Target Applications

Toshiba MG150H2DL1 is used for inverters and AC motor drives, servo drives, UPS systems, welding machines, induction heating, solar and wind power converters and other high-power switching equipment.

Key Specifications

MG150H2DL1 is a 150 A IGBT / power transistor module. Source: manufacturer datasheet.

Parameter	Value
Product type	IGBT / power transistor module
Collector current (IC)	150 A
Datasheet	Available on this page (PDF)
