SKM150GB128D Semikron - IGBT Module

SKM150GB128D Description

SKM150GB128D is a SPT IGBT module, SEMITRANS 3, half bridge from Semikron, rated 1200V, 200A. Typical applications: AC inverter drives, UPS and electronic welders.

USComponent supplies SKM150GB128D and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Summary of Features

Target Applications

Semikron SKM150GB128D is used for AC inverter drives, UPS and electronic welders.

Key Specifications

SKM150GB128D is a SPT IGBT module, SEMITRANS 3, half bridge from Semikron, rated 1200V, 200A. Source: manufacturer datasheet.

Parameter	Value
Manufacturer	Semikron
Collector-emitter voltage VCES	1200 V
IC (Tc = 25 / 80 °C)	200 / 140 A
ICRM (1 ms, 25 / 80 °C)	400 / 280 A
VCE(sat) typ. / max. (IC = 100 A, 25 °C)	1.9 V / 2.35 V
Inverse diode IF (25 / 80 °C)	150 / 100 A
Isolation voltage Visol	4000 V (AC, 1 min)
Package	SEMITRANS 3
Datasheet	Available on this page (PDF)

Note: Datasheet marked Preliminary Data.
