SKM145GB128D Semikron - IGBT Module

SKM145GB128D Description

SKM145GB128D is a SPT IGBT module, SEMITRANS 2, half bridge from Semikron, rated 1200V, 135A. Typical applications: AC inverter drives, UPS and electronic welders.

USComponent supplies SKM145GB128D and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Summary of Features

Target Applications

Semikron SKM145GB128D is used for AC inverter drives, UPS and electronic welders.

Key Specifications

SKM145GB128D is a SPT IGBT module, SEMITRANS 2, half bridge from Semikron, rated 1200V, 135A. Source: manufacturer datasheet.

Parameter	Value
Manufacturer	Semikron
Collector-emitter voltage VCES	1200 V
IC (Tcase = 25 / 80 °C)	190 / 135 A
ICRM	200 A
Short circuit withstand tpsc	10 µs
Inverse diode IF (25 / 80 °C)	130 / 90 A
Isolation voltage Visol	4000 V (AC, 1 min)
Package	SEMITRANS 2
Datasheet	Available on this page (PDF)

Technical document (PDF)  |  Request a quote for SKM145GB128D (reply within 24 hours)
