DD160F-120 Description

SanRex makes the DD160F-120, a diode module. Typical applications include AC-to-DC rectification in drives and power supplies, freewheeling paths and battery charging. If you are repairing older equipment, we can usually find this exact part, including date codes that are no longer in production.

USComponent is a BBB A+ accredited distributor that specializes in power modules and industrial components, new and legacy. Ask us for a quote on the DD160F-120; we ship worldwide. Please verify the ratings and package against the manufacturer's datasheet first.

Summary of Features

DD160F-120 is a Diode Module.

Target Applications

SanRex DD160F-120 is used for motor drives and inverters, servo amplifiers, UPS systems, welding machines and other industrial power switching equipment.

Key Specifications

Manufacturer	SanRex
Configuration	Diode module - two diodes in series, isolated mounting base
VRRM / VRSM	1200 V / 1300 V
Surge current IFSM	5000 / 5500 A (50 / 60 Hz)
Forward voltage VFM max.	1.42 V @ 500 A
Isolation voltage	2500 V (AC RMS, 1 min)
Mounting torque	M5: 1.5 - 2.5 N·m recommended
Weight	510 g
