RM200HA-12F Mitsubishi - Diode Module
RM200HA-12F Description
The Mitsubishi Electric RM200HA-12F is a diode module, rated for 1000 V and 200 A. It is used in input rectifiers, freewheeling and clamping circuits, battery chargers and welding power sources.
USComponent (Young & New Century LLC) supplies power modules, thyristors, diodes and other industrial components, including legacy parts. Contact us for a quote on the RM200HA-12F, and please confirm ratings against the datasheet before ordering.
Target Applications
Mitsubishi RM200HA-12F is used for Free wheel use and Welders.
Key Specifications
| Manufacturer | Mitsubishi Electric |
| Category | Diode Module |
| Rated voltage | 600 V |
| Rated current | 200 A |
Related Part Numbers
| RM200HA-10F 500V, 200A | RM300HA-12F 600V, 300A | RM200HA-20F 1000V, 200A | RM100HA-12F 600V, 100A |
| RM200HA-24F 1200V, 200A | RM50HA-12F 600V, 50A | RM250HA-10F 250A/500V | RM250HA-20F 1000V, 250A |
| RM200HA-24S 200A/1200V | RM200HC-20 1000V, 100A | RM200DZ-M 1000(V) / 200(A) | RM200DZ-H |
| RM200DZ-2H 1600V, 200A | RM200DY1-24S 1200 V, 200 A | RM200DA-20F 1000V, 200A | RM200CY-24S 1200 V, 200 A |
