QM20TD-9 Mitsubishi - Bipolar Transistor Module

Category: Darlington / Bipolar Transistor Modules

Specifications: 600V, 20A

QM20TD-9, Mitsubishi,  Power Transistor Module

Representative image – actual product may differ

Availability and lead time are confirmed in our quote.

  • ✓ Quote within 24 hours
  • ✓ Original manufacturer parts, inspected before shipping
  • ✓ Credit cards and NET terms accepted

Or email sales@uscomponent.com or call 1-281-968-0718.

QM20TD-9 Description

Mitsubishi Electric QM20TD-9 is a Darlington transistor module rated at 600 V and 20 A. Modules of this type were widely used in motor drives, UPS units and power supplies, and many are still running in older equipment today.

We help engineers and repair technicians find parts like the QM20TD-9, including obsolete ones. Send a quick RFQ for current pricing and delivery. Before ordering, please confirm ratings and pin-out with the official datasheet.

Summary of Features

QM20TD-9 is a 20 A power transistor (bipolar Darlington) module.

Target Applications

Mitsubishi QM20TD-9 is used for motor drives and inverters, servo amplifiers, UPS systems, welding machines and other industrial power switching equipment.

Key Specifications

QM20TD-9 is a 20 A power transistor (bipolar Darlington) module. Source: manufacturer datasheet.

ParameterValue
Product typePower transistor (bipolar Darlington) module
Collector current (IC)20 A
DatasheetAvailable on this page (PDF)

Technical document (PDF)  |  Request a quote for QM20TD-9 (reply within 24 hours)
