QM200DY-HMitsubishi - Power Transistor Module

QM200DY-H Description

The Mitsubishi Electric QM200DY-H is a Darlington transistor module rated at 500 V and 200 A, available from USComponent. High Power Switching Use Insulated Type Transistor Module. Typical applications for this type of device include motor drives, UPS systems and power supplies; transistor modules of this type are largely superseded by IGBTs in new designs but remain essential for maintaining installed equipment.

USComponent supplies power semiconductors and industrial electronic components to engineers, OEMs and maintenance teams worldwide, including legacy and hard-to-find part numbers. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the QM200DY-H.

Target Applications

Mitsubishi QM200DY-H is used for motor drives and inverters, servo amplifiers, UPS systems, welding machines and other industrial power switching equipment.

Key Specifications

Manufacturer	Mitsubishi Electric
Category	Power Transistor Modules
Rated voltage	500 V
Rated current	200 A

Download QM200DY-H Datasheet

QM200DY-H PDF Datasheet
