QM150DY-HBMitsubishi - Power Transistor Module

QM150DY-HB Description

The Mitsubishi Electric QM150DY-HB is a Darlington transistor module rated at 600 V and 150 A, available from USComponent. MITSUBISHI TRANSISTOR MODULES HIGH POWER SWITCHING USE INSULATED TYPE. Typical applications for this type of device include motor drives, UPS systems and power supplies; transistor modules of this type are largely superseded by IGBTs in new designs but remain essential for maintaining installed equipment.

USComponent supplies power semiconductors and industrial electronic components to engineers, OEMs and maintenance teams worldwide, including legacy and hard-to-find part numbers. Please confirm ratings, package and pin-out against the manufacturer's datasheet before ordering, and request a quote for current pricing and lead time on the QM150DY-HB.

Target Applications

Mitsubishi QM150DY-HB is used for Inverters, Servo Drives, UPS, DC Motor Controllers, NC Equipment and Welders.

Key Specifications

Manufacturer	Mitsubishi Electric
Category	Power Transistor Modules
Rated voltage	600 V
Rated current	150 A

Download QM150DY-HB Datasheet

QM150DY-HB PDF Datasheet
