QM150DX-H Mitsubishi - Power Transistor Module

Category: Darlington / Bipolar Transistor Modules

Specifications: 600V, 150A

QM150DX-H, MTSUBISHI, High Power Switching Use Insulated Type Transistor Module

Representative image – actual product may differ

We beat competitor's price with faster delivery.

For 6 pieces or more, submit your inquiry here, email to sales@uscomponent.com or call 1-281-968-0718

QM150DX-H Description

The QM150DX-H from Mitsubishi Electric is a Darlington transistor module with a 600 V / 150 A rating. You will mostly see it in older AC drives, servo amplifiers and UPS systems, where a like-for-like replacement keeps the machine running.

USComponent (Young & New Century LLC) supplies power modules, thyristors, diodes and other industrial components, including legacy parts. Contact us for a quote on the QM150DX-H, and please confirm ratings against the datasheet before ordering.

Summary of Features

QM150DX-H is a 150 A power transistor (bipolar Darlington) module.

Target Applications

Mitsubishi QM150DX-H is used for Inverters, Servo Drives, UPS, DC Motor Controllers, NC Equipment and Welders.

Key Specifications

QM150DX-H is a 150 A power transistor (bipolar Darlington) module. Source: manufacturer datasheet.

ParameterValue
Product typePower transistor (bipolar Darlington) module
Collector current (IC)150 A
DatasheetAvailable on this page (PDF)

Technical document (PDF)  |  Request a quote for QM150DX-H (reply within 24 hours)

Related Part Numbers

QM120DX-H
500V, 120A		QM100DX-H
600V, 100A		QM75DX-H
600V, 75A		QM50DX-H
600V, 50A
QM30DX-H
600V, 30A		QM20DX-H
600V, 20A		QM15DX-H
600V, 15A		QM150DY-HBK
600V, 150A
QM150DH-HQM150DY-24QM150DY-24BQM150DY-24BK
QM150DY-24HQM150DY-24KQM150DY-2HQM150DY-2HA
