PS21564-G Mitsubishi - Intelligent Power Module

Category: Intelligent Power Modules (IPM)

Specifications: 15(V) / 30(A)

PS21564-G Mitsubishi Intelligent Power Module

Availability and lead time are confirmed in our quote.

  • ✓ Quote within 24 hours
  • ✓ Original manufacturer parts, inspected before shipping
  • ✓ Credit cards and NET terms accepted

Or email sales@uscomponent.com or call 1-281-968-0718.

PS21564-G Description

PS21564-G is a 15 V, 30 A intelligent power module (IPM) made by Mitsubishi Electric. Because the gate drivers and protection circuits are built in, it is popular in compact motor drives, servo amplifiers and appliance inverters. If you are repairing older equipment, we can usually find this exact part, including date codes that are no longer in production.

USComponent is a BBB A+ accredited distributor that specializes in power modules and industrial components, new and legacy. Ask us for a quote on the PS21564-G; we ship worldwide. Please verify the ratings and package against the manufacturer's datasheet first.

Summary of Features

Dual-In-Line Package Intelligent Power Module

Target Applications

Mitsubishi PS21564-G is used for AC100V~200V inverter drive for small power motor control.

Key Specifications

ManufacturerMitsubishi Electric
CategoryIntelligent Power Module
Rated voltage15 V
Rated current30 A

Related Part Numbers

PS21563-G
600V, 10A		PS21353-G
600V, 10A		PS21352-G
600V, 5A		PS21342-G
5A/600V
PS20351-G
AC MOTOR CONTROLLER, 6 A, DMA35		PS21564-CP
600V, 150A		PS21564-C
600V, 15A		PS21564-P
600V, 15A
PS21564PS21563-SP
600V, 10A		PS21563-S
600V, 10A		PS21563-P
600V, 10A
PS21563-CP
600(V) / 10(A)		PS21563-CPS21563
600V, 10A		PS21562
600V, 5A
