IRFK3D250 International Rectifier - MOSFET Module

IRFK3D250 Description

IRFK3D250 is an isolated base power HEX-pak MOSFET assembly, half bridge from International Rectifier, rated 200V, 70A.

USComponent supplies IRFK3D250 and other power semiconductors and power supplies, including discontinued types. Request a quote for price and lead time - we reply within 24 hours.

Summary of Features

Target Applications

International Rectifier IRFK3D250 is used for high-frequency power switching in switch mode power supplies, DC-DC converters, battery-powered vehicles and equipment, welding machines and induction heating.

Key Specifications

IRFK3D250 is an isolated base power HEX-pak MOSFET assembly, half bridge from International Rectifier, rated 200V, 70A. Source: manufacturer datasheet.

Parameter	Value
Manufacturer	International Rectifier
Drain-source voltage VDS	200 V
Continuous drain current ID (TC = 25 °C)	70 A
Pulse drain current IDM	280 A
On-resistance RDS(on)	30 mΩ
Max. power dissipation	625 W
Isolation voltage	2.5 kV rms, circuit to base
Configuration	Half bridge
Package	HEX-pak (TO-240), 140 g
Datasheet	Available on this page (PDF)

Note: data taken from the International Rectifier datasheet of IRFK3D250 / IRFK3F250 (D = fast switching), which covers IRFK3D250.
